MR56

• The Cisco Meraki MR56 is a cloud-managed 8×8:8 802.11ax access point that raises the bar for wireless performance and efficiency. Designed for nextgeneration deployments in offices, schools, hospitals, shops, and hotels, the MR56 offers high throughput, enterprise-grade security, and simple management. The MR56 provides a maximum of 5.9 Gbps* aggregate frame rate with concurrent 2.4 GHz and 5 GHz radios. A dedicated third radio provides real-time WIDS/ WIPS with automated RF optimization, and a fourth integrated radio delivers Bluetooth scanning and beaconing. With the combination of cloud management, high performance hardware, multiple radios, and advanced software features, the MR56 makes an outstanding platform for the most demanding of uses-including high-density deployments and bandwidth or performance-intensive applications like voice and high-definition video. MR56 and Meraki Cloud Management Management of the MR56 is performed through the Meraki cloud, with an intuitive browser-based interface that enables rapid deployment without time consuming training or costly certifications. Because the MR56 is self-configuring and managed over the web, it can be deployed at a remote location in a matter of minutes, even without on-site IT staff. 24×7 monitoring via the Meraki cloud delivers real-time alerts if a network encounters problems. Remote diagnostic tools enable immediate troubleshooting over the web so that distributed networks can be managed with a minimum of hassle. The MR56’s firmware is automatically kept up to date via the cloud. New features, bug fixes, and enhancements are delivered seamlessly over the web. This means no manual software updates to download or missing security patches to worry about. Product Highlights 8×8:8 MU-MIMO 802.11ax 5.9 Gbps dual-radio aggregate frame rate 24×7 real-time WIDS/WIPS and spectrum analytics via dedicated third radio Integrated Bluetooth Low Energy Beacon Integrated scanning radio Enhanced transmit power and receive sensitivity Integrated enterprise security and guest access Application-aware traffic shaping Optimized for voice and video Self-configuring, plug-and-play deployment Sleek design blends into office environments Full-time Wi-Fi location tracking via dedicated 3rd radio Features Dual-radio aggregate frame rate of up to 5.9 Gbps 5 GHz 8×8:8 radio and 2.4 GHz 4×4:4 radio offer a combined dual-radio aggregate frame rate of 5.9 Gbps, with up to 4,804 Mbps in the 5 GHz band and 1,147 Mbps in the 2.4 GHz band. Technologies like transmit beamforming and enhanced receive sensitivity allow the MR56 to support a higher client density than typical enterprise-class access points, resulting in better performance for more clients, from each AP. Multi User Multiple Input Multiple Output (MU-MIMO) With support for features of 802.11ax, the MR56 offers MU-MIMO and OFDMA for more efficient transmission to multiple clients. Especially suited to environments with numerous mobile devices, MU-MIMO enables multiple clients to receive data simultaneously. This increases the total network performance and improves the end user experience.



  Product Type: Wireless Access Point



  Technical Information:

  Wireless LAN Standard: 802.11ax



  Frequency Band: 2.40 GHz



  Frequency Band: 5 GHz



  Wireless Transmission Speed: 5.90 Gbit/s



  MIMO Technology: Yes



  Beamforming Technology: Yes



  Interfaces/Ports:

  Ethernet Technology: 5 Gigabit Ethernet



  Number of Network (RJ-45) Ports: 1



  Physical Characteristics:

  Form Factor: Desktop



  Form Factor: Ceiling Mountable



  Form Factor: Wall Mountable



  Form Factor: Rail-mountable



  Height: 1.8″



  Width: 12.8″



  Depth: 5.5″



  Weight (Approximate): 2.20 lb
